Red Sea REEFER™ XL Concept

200 | 300 | 425 | 525

The REEFER XL includes four models that give you the freedom to create more expansive, intricate, and diverse reefscapes without the constraints of the smaller tanks. All four XL models are 57.5cm (22.6″) wide and 55 cm (22″) high (excluding XL 200, which is 53 cm/21″ high). They differ in length and are available in 4 sizes from 60cm (24″) long/200 liter (53 gal) capacity up to 150cm (59″) long/525 liter (140 gal). All the REEFER XL models now feature a laminated, plywood marine-spec cabinet for greater water resistance with adjustable feet for perfect leveling on any surface.

REEFER™ XL Models
	Specs	XL 200	XL 300	XL 425	XL 525
Main Features	Ultra clear front and side glass
	Ultra clear front glass thickness (mm)	10 (3/8″)	12 (1/2″)	12 (1/2”)	15 (5/8”)
	Built in surface skimmer
	Integrated automatic top up system
System Volumes	Display tank water volume (L)	158 (42 gal)	246 (65 gal)	332 (88 gal)	409 (108 gal)
	In cabinet sump water volume (L)	42 (11 gal)	54 (15 gal)	90 (24 gal)	116 (31 gal)
	Total system water volume (L)	200 (53 gal)	300 (80 gal)	422 (112 gal)	525 (139 gal)
	RO reservoir volume (L)	6.7 (1.8 gal)	12.3 (3.2 gal)	20.8 (5.5 gal)	20.8 (5.5 gal)
System Dimensions	Display tank length (cm)	60 (24″)	90 (36″)	120 (47″)	150 (59″)
	Display tank height (cm)	53 (21″)	55 (22″)	55 (22″)	55 (22″)
	Display tank width (cm)	57.5 (22.6″)	57.5 (22.6″)	57.5 (22.6″)	57.5 (22.6″)
	Total system height with cabinet (cm)	140 (55″)	142 (56″)	142 (56″)	142 (56″)
Sump Dimensions	Water height (cm)	17-23 (6.7-9″)	17-23 (6.7-9″)	20-27 (7.9”-10.6”)	20-27 (7.9”-10.6”)
	Skimmer chamber without Refugium wall (cm)	30 x 28 (11.8″ x 11″)	47 x 25 (16.5″ x 9.8″)	48 x 36 (19.3” x 14.1”)	56 x 48 (22” x 19.3”)
	Skimmer chamber with Refugium wall (cm)	30 x 28 (11.8″ x 11″)	25 x 25 (9.8″ x 9.8)	25 x 36 (9.8″ x 14.2″)	56 x 25 (22″ x 9.8″)
	Pump chamber (cm)	30 x 14 (11.8″ x 5.5″)	26 x 17 (10.2″ x 6.7″)	26 x 24 (10.2” x 9.4”)	26 x 24 (10.2” x 9.4”)
Return Pump	3/4” threaded hose barb – Pipe Int. Dia	16mm (5/8″)	16mm (5/8″)	25mm (1”)	25mm (1”)
	Recommended flow (lph) (pump not included)	2000 (530 gph)	2500 (660 gph)	4000 (1060 gph)	4000 (1060 gph)
Deluxe Series Features	ReefLED™ 90	1 Unit 90W	2 Unit 180W	2 Unit 180W	3 Unit 270W
New Special Features	Adjustable Height Skimmer Chamber
	Refugium Ready
	225 micron Thin-mesh Filter Bag	1	1	2	2
	Filter Media Cup		1	2	2
	Quick Release cabinet door hinges
	Heavy Duty levelable Plywood Cabinet
